DC Gasoline Pump
This pump is designed, tested and approved for use with thin viscosity petroleum fuels such as gasoline blends(up to E15),diesel fuel blends (up to B20) and kerosene. Please take all due precautions when handling these flammable liquids Do not use this pump for transfering any fluids other than those for which it was designed.
Yoilp 1228-3 12V
Double way switch
The switch futures double way function:
" I " : pump ON and flow move by the arrow direction.
" O ": pump OFF.
" R ": pump ON and run reversely.
• Power: 20W
• Voltage: DC12V
• Max. Head.: 5m
• Flow Range: 7.5Lpm
• Working Amps: 1.5A
• Compatible Fluids: Gasoline/Diesel/Water
• Caution: Don't operate without water.
• IPX8
• With AC/DC charger
- 技术参数
- 详细描述
-
- Commodity name: DC Gasoline Pump
- Commodity ID: F-A008
- 产品型号: Yoilp 1228-3 12V
This pump is designed, tested and approved for use with thin viscosity petroleum fuels such as gasoline blends(up to E15),diesel fuel blends (up to B20) and kerosene. Please take all due precautions when handling these flammable liquids Do not use this pump for transfering any fluids other than those for which it was designed.
Features:
1. Before electrical installation, ensure all parts are well installed, connected,grounded and well sealed.
2. Place the switch into the OFF position to prevent accidental spillage once power is engaged to the motor.
3. Pass the electrical wires to the power source and make sure the alligator clips are correctly connect to the negative (-) orpositive (+) poles on the power source. -
Double way switch
The switch futures double way function:
" I " : pump ON and flow move by the arrow direction.
" O ": pump OFF.
" R ": pump ON and run reversely.• Power: 20W
• Voltage: DC12V
• Max. Head.: 5m
• Flow Range: 7.5Lpm
• Working Amps: 1.5A
• Compatible Fluids: Gasoline/Diesel/Water
• Caution: Don't operate without water.
• IPX8
• With AC/DC charger
Features:
1. Before electrical installation, ensure all parts are well installed, connected,grounded and well sealed.
2. Place the switch into the OFF position to prevent accidental spillage once power is engaged to the motor.
3. Pass the electrical wires to the power source and make sure the alligator clips are correctly connect to the negative (-) orpositive (+) poles on the power source.
