DC fuel transfer pumps
Displacement, self-priming, rotary electric vane pumps for the transfer of diesel fuel equipped with by-pass valve.
Yoilp1229C 12V
• 80L/MIN, • 22GPM • 2000RPM • 1"BSP • 44A(12V),21A(24V) • 11KGS • 1/CTN 12/11KGS 31X20.5X21CM
- 技术参数
- 详细描述
-
- Commodity name: DC fuel transfer pumps
- Commodity ID: D-A005
- 产品型号: Yoilp1229C 12V
- 参数: • 80L/MIN, • 22GPM • 2000RPM • 1"BSP • 44A(12V),21A(24V) • 11KGS • 1/CTN 12/11KGS 31X20.5X21CM
Displacement, self-priming, rotary electric vane pumps for the transfer of diesel fuel equipped with by-pass valve.
DC fuel transfer pumps
Powerful, dependable and economical, they are available with 12 and 24-volt direct current motors.
Technical specifications
• Cast iron pump body finished with anti-corrosion paint.
• Vane pump with sintered steel rotor and acetal resin vanes.
• By-pass valve incorporated in the pump body.
• Direct current brush motor with permanent magnet stator.
• Motor protection grade IP55.
• Used in intermittent service with 30-minute work cycles.
DC fuel transfer pumps
Powerful, dependable and economical, they are available with 12 and 24-volt direct current motors.
Technical specifications
• Cast iron pump body finished with anti-corrosion paint.
• Vane pump with sintered steel rotor and acetal resin vanes.
• By-pass valve incorporated in the pump body.
• Direct current brush motor with permanent magnet stator.
• Motor protection grade IP55.
• Used in intermittent service with 30-minute work cycles.
Keywords:
RELEVANT
DC PUMPS
1225B 12V
• 50L/MIN, 13GPM • 260W • 2600RPM • 1" • 24A(12V),17A(24V) • 1.5BAR • 3.5KGS • 4/CTN 19/18KGS 36X23X32CM
DC PUMPS
1225C 12V
• 50L/MIN • 260W • 2600RPM • 3/4" • 22A(12V),11A(24V) • 1.5BAR • 3.5KGS • 4/CTN 19/18KGS 36X23X32CM
DC PUMPS
Yoilp1229B 24V/12V
• 1" BSP • 25A(24V), 16A(12V) • 7.5 KGS • 1/CTN 28X18X20CM
